RAVIAN™ 52 inch 5-Blade Ceiling Fan With Remote and Dimmable Light - Matte Black

$299.97 $359.96



Ravian™ is a sleek and powerful Ceiling Fan with a clean minimalist style.  This model has 5 blades and a 52-inch blade sweep with a modern cylinder shaped motor case. The fan blades are made from solid ABS material which is ultra-durable and can handle damp locations without sagging.  The powerful and efficient DC motor is loaded with features including six speeds, auto-reverse and two sleep-timer settings.  Ravian™ is rated for use in dry and damp locations, including covered porches.  The bright 20 watt LED Light Kit is fully dimmable and has 5 different CCT color settings, using the included remote control.

Features

Ideal for rooms with 9-foot ceilings and higher
Ideal for room sizes 175 to 350 square feet
Sloped ceiling compatible up to 19 degrees
Comes with 6-inch downrod.
Other downrod sizes available to order; 4-in, 12-in, 18-in, 24-in, 36-in, 48-in, 60-in, 72-in
Damp rated for using in Dry and Damp locations, including covered porches
Light Kit is fully dimmable and has 5 CCT color temperatures to choose from
Comes with Powerful and high-efficiency DC motor
Six speed air control
Fan and lights are controlled by the included remote
In-Wall remote available as optional accessory - Model AR-DCWALL
CA65 Compliant

Dimensions

Canopy Width (Inches) 5.35
Canopy Height (Inches) 2.2
Blade Sweep (Inches) 52
Overall Height (Inches) with included 6" Downrod 14.41
Item weight 13.1 lbs.

Specifications

Third Party Safety Rating - cUL
Rating Service File Number 4791226963
Power Source - Hard Wired
Lead Wire Length (Inches) 12
Fixture Voltage 120V

Blade Specs

Blade Pitch (Degrees) - 13
Blade Material - ABS
Blade Thickness (MM) - 3.2

Motor Specs

Motor Size - DCS-15NS-1
Motor RPM high speed - 135
Motor Reversible - Yes
Airflow CFM Low Speed - 2140.88
Airflow CFM Medium Speed - 4503.73
Airflow CFM High Speed - 5902.02

Light Kit Specs

Light Kit Max Watts
• 2700k: 20w
• 3000k: 22.87w
• 3500k: 22.87w
• 4000k: 22.63w
• 5000k: 20.45w
Light Kit Max Effective Lumens
• 2700k: 1450 lm
• 3000k: 1631 lm
• 3500k: 1736 lm
• 4000k: 1717 lm
• 5000k: 1560 lm
Light Kit Color Rendering Index (CRI)
• 2700k: 84.8
• 3000k: 86.3
• 3500k: 88.3
• 4000k: 88.6
• 5000k: 86.9



Ravian™ is a sleek and powerful Ceiling Fan with a clean minimalist style.  This model has 5 blades and a 52-inch blade sweep with a modern cylinder shaped motor case. The fan blades are made from solid ABS material which is ultra-durable and can handle damp locations without sagging.  The powerful and efficient DC motor is loaded with features including six speeds, auto-reverse and two sleep-timer settings.  Ravian™ is rated for use in dry and damp locations, including covered porches.  The bright 20 watt LED Light Kit is fully dimmable and has 5 different CCT color settings, using the included remote control.
